Guangzhou Xucai Environmental Technology Co., Ltd. is one of the leading manufacturers and suppliers of powder vibrating screen separator in China. If you're going to buy customized powder vibrating screen separator made in China, welcome to get quotation from our factory. For price consultation, contact us.
Powder Vibrating Screen Features:
Equipped with a high-quality vibration motor for high vibration frequency and fast screening speed.
The screen has a large load capacity, effectively extending its service life. A punched plate screen is available as a customization option.
The circular vibrating screen includes a special cleaning layer with built-in bouncing balls to effectively clean the screen and increase screening speed.
This equipment can be configured with 1-5 screen layers, allowing for multi-stage sorting to improve efficiency.
The screen frame joints use a sealing ring and an external fastening ring, providing good sealing performance, safety, and stability.
A stainless steel hopper can be installed at the inlet, and the outlet can be positioned at any angle within 360° for easy operation.
Screen aperture size is selectable, and screen changes are convenient.
Ultra-fine mesh can be selected for ultrasonic screen cleaning.
All material-contacting parts are made of 304 stainless steel, with an option for SS316.
Technical parameters:
|
Model |
Sieve Diameter (mm) |
Effective Sieve Area(m2) |
Sieve Specification (mesh) |
Size |
Sieve Layers (layer) |
Vibration Times (times/min) |
Power (kw) |
|
TPM-400 |
360 |
0.09 |
2-325 |
580x580x560 |
1 |
1500 |
0.25 |
|
580x580x670 |
2 |
||||||
|
580x580x780 |
3 |
||||||
|
TPM-600 |
560 |
0.22 |
2-325 |
800x800x750 |
1 |
1500 |
0.55 |
|
800x800x890 |
2 |
||||||
|
800x800x1030 |
3 |
||||||
|
TPM-800 |
760 |
0.4 |
2-325 |
900x900x750 |
1 |
1500 |
0.75 |
|
900x900x890 |
2 |
||||||
|
900x900x1030 |
3 |
||||||
|
TPM-1000 |
930 |
0.63 |
2-325 |
1160x1160x810 |
1 |
1500 |
1.1 |
|
1160x1160x950 |
2 |
||||||
|
1160x1160x1090 |
3 |
||||||
|
TPM-1200 |
1130 |
0.95 |
2-325 |
1360x1360x885 |
1 |
1500 |
1.5 |
|
1360x1360x1050 |
2 |
||||||
|
1360x1360x1275 |
3 |
||||||
|
TPM-1500 |
1430 |
1.5 |
2-325 |
1850x1850x990 |
1 |
1500 |
2.2 |
|
1850x1850x1185 |
2 |
||||||
|
1850x1850x1350 |
3 |
||||||
|
TPM-1800 |
1730 |
2.3 |
2-325 |
2200x2200x1050 |
1 |
1500 |
2.2 |
|
2200x2200x1250 |
2 |
||||||
|
2200x2200x1450 |
3 |
Vibrating screens are typically used for screening granular and powder materials and can also filter liquid materials. The screened materials are uniform in size, and the machine operates with low noise. The vibrating screen can work continuously for 24 hours.
Why choose us?
1.With more than 10 years of experience in producing plastic machinery, we can offer expert knowledge to our customers.
2.With high productivity and flexible, efficient management, we deliver products quickly and reliably.
3.With rigorously selected materials and skilled workers, the quality of our products not only meets your demands but also exceeds your expectations.
4.We maintain strict quality control, ensuring consistent product quality, competitive pricing, and professional services.
5.Our professional sales and export team helps customers save on import costs.
