Guangzhou Xucai Environmental Technology Co., Ltd. is one of the leading manufacturers and suppliers of plastic crusher rubber shredder in China. If you're going to buy customized plastic crusher rubber shredder made in China, welcome to get quotation from our factory. For price consultation, contact us.
Plastic Crusher Rubber Shredder Features
The Plastic Crusher Rubber Shredder is a high-performance shredding equipment for plastic and rubber waste processing. Its crushing chamber diameter ranges from 310×265mm to 1530×1000mm, crushing capacity from 150-2100kg/h and motor power from 5.5-75kw. It works via high-speed rotation of rotary cutters matching fixed cutters, cutting materials through blade clearance, then filtering and outputting particles of specified sizes through a screen. The equipment is built with a sturdy main machine structure, and the number of fixed and flexible cutters varies by model to adapt to different material hardness and processing scales.
Recycling & Material
What we use in production
PP strapping material
PE film material
denim fabric scrap
PU foam material
Features
Suitable for all kinds of film materials such as sheet, pipe, profile, plate, blow molding parts, bottle shell, packaging materials, PE, PP and so on.
The multi-function plastic shredder motor drives the rotary cutter to rotate at high speed, and the rotary cutter and the fixed cutter form relative movement tendency in the process of high-speed rotation. The clearance between rotary knife and fixed knife is used to cut, and the plastic nozzle scrap material is broken and cut, so that the large plastic rubber head is broken. The broken plastic material is filtered and output the size of plastic plastic particles through the screen.
The structure of the main machine is well designed, the crushing capacity is strong, the special feeding port design material is not splash, safe and reliable.
4.Unique blade design, easy crushing all kinds of soft and hard plastic.
Unique blade design, easy crushing all kinds of soft and hard plastic.
Motor inside made of copper wire,long use time,not easy happen overheat.
The motor is equipped with overload protection device and interlocking protection system with power supply.
The motor is equipped with overload protection device and interlocking protection system with power supply.
When replacing the cutter, the gap between the moving and fixed cutter: 0.8mm above 20HP crusher is good, and 0.5mm below 20HP crusher is good.
Technical parameters
Details
Crushing Chamber
Separable design with screw/cylinder open-close (≥22kw), accommodating various material volumes.
Screen
Standard 8/10/12mm mesh; customizable 4-60mm to meet specific particle size needs.
Motor
High-efficiency copper core with overload protection, low noise, and energy-saving performance.
Pulley
High-quality assembly with wear-resistant belt, ensuring stable and long-lasting power transmission.
Feeding Hopper
Modular structure with reference hole assembly, facilitating easy loading and disassembly.
Safety Switch
Industrial-grade limit switch, withstands 10,000+ operations to protect operators.
Control Switch
Intuitive interface with clear labels, enabling precise and simple operation for workers.
Electrical Components
Adopts Schneider Electric parts, ensuring reliable performance and low failure rates.
Bearing
Heavy-load design with oil seal, preventing vibration and grease contamination of processed materials.
Application Scenarios
Plastic product production: Shredding defective products, leftover materials and nozzle scraps in plastic manufacturing workshops.
Rubber and plastic recycling: Processing waste plastic pipes, barrels, film and rubber products in recycling centers.
Packaging material disposal: Crushing various plastic packaging waste generated in industrial and commercial fields.
Chemical container processing: Shredding waste chemical barrels, paint barrels and other plastic storage containers for resource reuse.
fAQ
Q1: Can I send samples to test the machine's crushing effect?
A1: Yes, you can send plastic bottle/can samples to our factory for testing, and we will provide a detailed test video to verify performance.
Q2: How to ensure fund security for bulk orders?
A2: We support Alibaba.com Guarantee Service to protect your funds. We also share weekly production photos to keep you updated on order progress.
Q3: Can the crusher be customized for specific bottle sizes (e.g., 1.5L PET bottles)?
A3: Yes, we adjust blade clearance and sieve size for targeted processing of specific bottle/can dimensions, ensuring optimal efficiency.
Q4: Is the equipment compatible with existing blower collection systems?
A4: Yes, the stainless steel storage bin is designed with universal interfaces, supporting direct integration with most industrial blower collection setups.
Q5: What is the maintenance cycle for key components (blades, bearings)?
A5: Blades require sharpening every 3–6 months (depending on usage); bearings need lubrication every 1–2 months. We provide detailed maintenance guidelines for bulk buyers.
