Guangzhou Xucai Environmental Technology Co., Ltd. is one of the leading manufacturers and suppliers of mould temperature controller water type in China. If you're going to buy customized mould temperature controller water type made in China, welcome to get quotation from our factory. For price consultation, contact us.
Mould temperature controller feature:
1. Imported magnetic pump is used, high temperature resistance, high pressure resistance, ultra-low noise pump, high stability, drip-proof, plus auxiliary booster pump, double pump booster, high pressure, high water temperature.
2. The control system adopts PLC Schneider and CHINT Electric to ensure the quality of electrical appliances to prolong the life of the electrical appliances. The brand controller has a full touch screen and dual-temperature display for backwater and outlet water.
3. Use stainless steel valve, multi inlet and multi outlet 304 stainless steel connection, the mold inlet is connected to the hot water inlet of the machine, and the mold inlet is connected to the hot water outlet of the machine
4. The interior is made of stainless steel seamless steel pipes. The standard model has a high temperature of 120°C, and the temperature below 120°C can be completely drip-proof.
5. The use of high-efficiency water circulation pumps can be used in the temperature control requirements of precision molds and small-diameter mold circuits to achieve precise temperature control and efficient heat exchange.
6. The appearance design is beautiful and generous, easy to disassemble and easy to maintain.
7. Built-in safety protection system, temperature abnormal alarm, emergency stop safety protection and indicator lights, etc.
Technical parameters:
|
Model |
Water Pump (kw) |
Pump Flowing volume (L/min) |
Heating Power (kw) |
Heat Conducting Medium |
Highest Temperature |
Dimension (mm) |
Weight (kg) |
|
TLOB-6WL |
0.37 |
40 |
6 |
Water |
98-120℃ |
610x320x690 |
45 |
|
TLOB-9WL |
0.75 |
90 |
9 |
Water |
98-120℃ |
610x320x690 |
50 |
|
TLOB-12WL |
0.75 |
90 |
12 |
Water |
98-120℃ |
610x320x690 |
65 |
|
TLOB-18WL |
1.1 |
140 |
18 |
Water |
98-120℃ |
800x325x780 |
65 |
|
TOB-24WL |
1.1 |
140 |
24 |
Water |
98-120℃ |
800x325x800 |
70 |
|
TOB-30WL |
1.5 |
168 |
30 |
Water |
98-120℃ |
800x325x800 |
90 |
|
TOB-36WL |
2.2 |
200 |
36 |
Water |
98-120℃ |
800x400x920 |
110 |
|
TOB-6WH |
0.37 |
40 |
6 |
Oil |
160-200℃ |
610x320x690 |
55 |
|
TOB-9WH |
0.75 |
90 |
9 |
Oil |
160-200℃ |
610x323x690 |
60 |
|
TOB-12WH |
0.75 |
90 |
12 |
Oil |
160-200℃ |
610x320x690 |
75 |
|
TOB-18WH |
1.1 |
140 |
18 |
Oil |
160-200℃ |
800x325x780 |
75 |
|
TOB-24WH |
1.1 |
140 |
24 |
Oil |
160-200℃ |
800x325x800 |
120 |
|
Notice:we can according customers request make oil type heat 300℃ |
|||||||
